ESP32-CAM - FT232RL ESPHome

BLG · Mars 20, 2023, 11:21

Bob · Mars 20, 2023, 11:48

Bonjour,
@BLG, tu peux mettre ton fichier yaml stp, essaie avec une résolution de 1600x1200.
Dans ta dernière capture, c’est qu’elle appli que tu utilises ?
Combien de méga pixel la caméra ?
Bob

jrvrcd · Mars 20, 2023, 12:00

Salut

peux tu nous fournir une photo de ta camera ,
un lien ou tu l’as acheté, un lien vers la doc ???

BLG · Mars 20, 2023, 12:12

salut,

voici l’achat sur aliexpress

jrvrcd · Mars 20, 2023, 12:20

j’ai trouvé ca

ton modele semble etre un ESP32 CAM MB (le MB est tres important)

j’ai vu cela aussi

BLG · Mars 20, 2023, 12:23

re:
voici mon fichier yaml

 name: esp32camgarage
 friendly_name: ESP32CAMgarage

esp32:
 board: esp32dev
 framework:
   type: arduino

esp32_camera:
 name: My Camera
 external_clock:
   pin: GPIO27
   frequency: 20MHz
 i2c_pins:
   sda: GPIO25
   scl: GPIO23
 data_pins: [GPIO17, GPIO35, GPIO34, GPIO5, GPIO39, GPIO18, GPIO36, GPIO19]
 vsync_pin: GPIO22
 href_pin: GPIO26
 pixel_clock_pin: GPIO21
 reset_pin: GPIO15
 resolution: 640x480
 jpeg_quality: 10
 vertical_flip: False

# Entite Camera Status
binary_sensor:
 - platform: status
   name: "Camera Status"

# Entite Restart Camera
switch:
 - platform: restart
   name: "Restart Camera"

# Entite temps d'utilisation et signal wifi
sensor:
 - platform: uptime
   name: Uptime Sensor
 - platform: wifi_signal
   name: "WiFi Signal dB"
   id: wifi_signal_db
   update_interval: 60s
   entity_category: "diagnostic"


light:
 - platform: binary
   name: "Desk Lamp"
   output: light_output

output:
 - id: light_output
   platform: gpio
   pin: GPIO4


# Enable logging
logger:

# Enable Home Assistant API
api:
 encryption:
   key: "rZPgkEjJ2bdPqn3wQAmiaEhwQhIxer02pje/304iY7A="

ota:
 password: "55da6bf68ec809b5257496dc26b55079"

wifi:
 ssid: !secret wifi_ssid
 password: !secret wifi_password

 # Enable fallback hotspot (captive portal) in case wifi connection fails
 ap:
   ssid: "Esp32Camgarage Fallback Hotspot"
   password: "GSUvDR0fvf8L"

captive_portal:
   esphome:
 name: esp32camgarage
 friendly_name: ESP32CAMgarage

esp32:
 board: esp32dev
 framework:
   type: arduino

esp32_camera:
 name: My Camera
 external_clock:
   pin: GPIO27
   frequency: 20MHz
 i2c_pins:
   sda: GPIO25
   scl: GPIO23
 data_pins: [GPIO17, GPIO35, GPIO34, GPIO5, GPIO39, GPIO18, GPIO36, GPIO19]
 vsync_pin: GPIO22
 href_pin: GPIO26
 pixel_clock_pin: GPIO21
 reset_pin: GPIO15
 resolution: 640x480
 jpeg_quality: 10
 vertical_flip: False

# Entite Camera Status
binary_sensor:
 - platform: status
   name: "Camera Status"

# Entite Restart Camera
switch:
 - platform: restart
   name: "Restart Camera"

# Entite temps d'utilisation et signal wifi
sensor:
 - platform: uptime
   name: Uptime Sensor
 - platform: wifi_signal
   name: "WiFi Signal dB"
   id: wifi_signal_db
   update_interval: 60s
   entity_category: "diagnostic"


light:
 - platform: binary
   name: "Desk Lamp"
   output: light_output

output:
 - id: light_output
   platform: gpio
   pin: GPIO4


# Enable logging
logger:

# Enable Home Assistant API
api:
 encryption:
   key: "rZPgkEjJ2bdPqn3wQAmiaEhwQhIxer02pje/304iY7A="

ota:
 password: "55da6bf68ec809b5257496dc26b55079"

wifi:
 ssid: !secret wifi_ssid
 password: !secret wifi_password

 # Enable fallback hotspot (captive portal) in case wifi connection fails
 ap:
   ssid: "Esp32Camgarage Fallback Hotspot"
   password: "GSUvDR0fvf8L"

captive_portal:
``esphome:
 name: esp32camgarage
 friendly_name: ESP32CAMgarage

esp32:
 board: esp32dev
 framework:
   type: arduino

esp32_camera:
 name: My Camera
 external_clock:
   pin: GPIO27
   frequency: 20MHz
 i2c_pins:
   sda: GPIO25
   scl: GPIO23
 data_pins: [GPIO17, GPIO35, GPIO34, GPIO5, GPIO39, GPIO18, GPIO36, GPIO19]
 vsync_pin: GPIO22
 href_pin: GPIO26
 pixel_clock_pin: GPIO21
 reset_pin: GPIO15
 resolution: 640x480
 jpeg_quality: 10
 vertical_flip: False

# Entite Camera Status
binary_sensor:
 - platform: status
   name: "Camera Status"

# Entite Restart Camera
switch:
 - platform: restart
   name: "Restart Camera"

# Entite temps d'utilisation et signal wifi
sensor:
 - platform: uptime
   name: Uptime Sensor
 - platform: wifi_signal
   name: "WiFi Signal dB"
   id: wifi_signal_db
   update_interval: 60s
   entity_category: "diagnostic"


light:
 - platform: binary
   name: "Desk Lamp"
   output: light_output

output:
 - id: light_output
   platform: gpio
   pin: GPIO4


# Enable logging
logger:

# Enable Home Assistant API
api:
 encryption:
   key: "rZPgkEjJ2bdPqn3wQAmiaEhwQhIxer02pje/304iY7A="

ota:
 password: "55da6bf68ec809b5257496dc26b55079"

wifi:
 ssid: !secret wifi_ssid
 password: !secret wifi_password

 # Enable fallback hotspot (captive portal) in case wifi connection fails
 ap:
   ssid: "Esp32Camgarage Fallback Hotspot"
   password: "GSUvDR0fvf8L"

captive_portal:esphome:
 name: esp32camgarage
 friendly_name: ESP32CAMgarage

esp32:
 board: esp32dev
 framework:
   type: arduino

esp32_camera:
 name: My Camera
 external_clock:
   pin: GPIO27
   frequency: 20MHz
 i2c_pins:
   sda: GPIO25
   scl: GPIO23
 data_pins: [GPIO17, GPIO35, GPIO34, GPIO5, GPIO39, GPIO18, GPIO36, GPIO19]
 vsync_pin: GPIO22
 href_pin: GPIO26
 pixel_clock_pin: GPIO21
 reset_pin: GPIO15
 resolution: 640x480
 jpeg_quality: 10
 vertical_flip: False

# Entite Camera Status
binary_sensor:
 - platform: status
   name: "Camera Status"

# Entite Restart Camera
switch:
 - platform: restart
   name: "Restart Camera"

# Entite temps d'utilisation et signal wifi
sensor:
 - platform: uptime
   name: Uptime Sensor
 - platform: wifi_signal
   name: "WiFi Signal dB"
   id: wifi_signal_db
   update_interval: 60s
   entity_category: "diagnostic"


light:
 - platform: binary
   name: "Desk Lamp"
   output: light_output

output:
 - id: light_output
   platform: gpio
   pin: GPIO4


# Enable logging
logger:

# Enable Home Assistant API
api:
 encryption:
   key: "rZPgkEjJ2bdPqn3wQAmiaEhwQhIxer02pje/304iY7A="

ota:
 password: "55da6bf68ec809b5257496dc26b55079"

wifi:
 ssid: !secret wifi_ssid
 password: !secret wifi_password

 # Enable fallback hotspot (captive portal) in case wifi connection fails
 ap:
   ssid: "Esp32Camgarage Fallback Hotspot"
   password: "GSUvDR0fvf8L"

captive_portal:
   esphome:
 name: esp32camgarage
 friendly_name: ESP32CAMgarage

esp32:
 board: esp32dev
 framework:
   type: arduino

esp32_camera:
 name: My Camera
 external_clock:
   pin: GPIO27
   frequency: 20MHz
 i2c_pins:
   sda: GPIO25
   scl: GPIO23
 data_pins: [GPIO17, GPIO35, GPIO34, GPIO5, GPIO39, GPIO18, GPIO36, GPIO19]
 vsync_pin: GPIO22
 href_pin: GPIO26
 pixel_clock_pin: GPIO21
 reset_pin: GPIO15
 resolution: 640x480
 jpeg_quality: 10
 vertical_flip: False

# Entite Camera Status
binary_sensor:
 - platform: status
   name: "Camera Status"

# Entite Restart Camera
switch:
 - platform: restart
   name: "Restart Camera"

# Entite temps d'utilisation et signal wifi
sensor:
 - platform: uptime
   name: Uptime Sensor
 - platform: wifi_signal
   name: "WiFi Signal dB"
   id: wifi_signal_db
   update_interval: 60s
   entity_category: "diagnostic"


light:
 - platform: binary
   name: "Desk Lamp"
   output: light_output

output:
 - id: light_output
   platform: gpio
   pin: GPIO4


# Enable logging
logger:

# Enable Home Assistant API
api:
 encryption:
   key: "rZPgkEjJ2bdPqn3wQAmiaEhwQhIxer02pje/304iY7A="

ota:
 password: "55da6bf68ec809b5257496dc26b55079"

wifi:
 ssid: !secret wifi_ssid
 password: !secret wifi_password

 # Enable fallback hotspot (captive portal) in case wifi connection fails
 ap:
   ssid: "Esp32Camgarage Fallback Hotspot"
   password: "GSUvDR0fvf8L"

captive_portal:

sous home assistant je créer ma new device en esp32dev
puis j’utilise ESPHOME-FLASHER en utilisant le fichier bin et le port wchubserial
(je pense avoir un problème d’enregistrement sur ma box pour l’adresse ip…)

jrvrcd · Mars 20, 2023, 12:26

essaye avec le deuxième lien fourni
the eye of the home tu as un code qui semble correspondre a ta camera ( MB Multi board ??)
chaque type de camera a une affectation differentes des io de la camera d’ou la multitude de code.


esphome:
  name: esp_cam
  platform: ESP32
  board: esp32cam

wifi:
  ssid: "**********"
  password: "**********"

  ap:
    ssid: "Esp Cam Fallback Hotspot"
    password: "***********"

captive_portal:

# Enable logging
logger:

# Enable Home Assistant API
api:

ota:

esp32_camera:
  name: My Camera
  external_clock:
    pin: GPIO0
    frequency: 20MHz
  i2c_pins:
    sda: GPIO26
    scl: GPIO27
  data_pins: [GPIO5, GPIO18, GPIO19, GPIO21, GPIO36, GPIO39, GPIO34, GPIO35]
  vsync_pin: GPIO25
  href_pin: GPIO23
  pixel_clock_pin: GPIO22
  power_down_pin: GPIO32
  resolution: 640x480
  jpeg_quality: 10

BLG · Mars 20, 2023, 12:28

je suis vraiment désolé, voici mon Yaml
esphome:

 name: esp32cam-2
 friendly_name: esp32cam 2

esp32:
 board: esp32dev
 framework:
   type: arduino


# Entite Camera
esp32_camera:
 name: esp32cam-2
 external_clock:
   pin: GPIO0
   frequency: 20MHz
 i2c_pins:
   sda: GPIO26
   scl: GPIO27
 data_pins: [GPIO5, GPIO18, GPIO19, GPIO21, GPIO36, GPIO39, GPIO34, GPIO35]
 vsync_pin: GPIO25
 href_pin: GPIO23
 pixel_clock_pin: GPIO22
 power_down_pin: GPIO32
 brightness: 1
 resolution: 640x480
 max_framerate: 10 fps
 vertical_flip: False

# Entite Camera Status
binary_sensor:
 - platform: status
   name: "Camera Status"

# Entite Restart Camera
switch:
 - platform: restart
   name: "Restart Camera"

# Entite temps d'utilisation et signal wifi
sensor:
 - platform: uptime
   name: Uptime Sensor
 - platform: wifi_signal
   name: "WiFi Signal dB"
   id: wifi_signal_db
   update_interval: 60s
   entity_category: "diagnostic"


light:
 - platform: binary
   name: "Desk Lamp"
   output: light_output

output:
 - id: light_output
   platform: gpio
   pin: GPIO4

# Enable logging
logger:

# Enable Home Assistant API
api:
 encryption:
   key: "60BPf/XKSq/cPY9Rthw2mJEK2g7WlODmQLadg1EHHEk="

ota:
 password: "56c7f6c00f3a76e11db6e83554677355"

wifi:
 ssid: !secret wifi_ssid
 password: !secret wifi_password

 # Enable fallback hotspot (captive portal) in case wifi connection fails
 ap:
   ssid: "Esp32Cam-2 Fallback Hotspot"
   password: "LaXo4LNUPPLM"

captive_portal:

jrvrcd · Mars 20, 2023, 12:35

Ton code est bourré de fautes d’identications.

Copie celui dont je t’ai fait part et utilise le STP

BLG · Mars 20, 2023, 1:22

même résultat, Setup failed

jrvrcd · Mars 21, 2023, 12:39

est ce que tu arrives a pousser un firmware « vide » ?
dans esphome
new device
tu connectes ta camera
installe a partir du PC.

si oui essaye ensuite depousser le firmware complet par OTA
n’oublie pas de mettre dans le code le password OTA qui est défini dans le firmware « vide » ainsi que le deuxieme code encryption

BLG · Mars 22, 2023, 9:02

hello
merci pour vos réponse, après avoir effectué beaucoup d’essais, j’ai abandonné avec cette camera et j’en ai pris une nouvelle. Du premier coup j’ai réussi à la paramétrer .
J’ai remarqué quelle possède un RST derrière la carte et non sur le coté , je ferai un essai plus tard
merci JRVRCD, j’arrivai a pousser firmware presque vide mais a la fin toujours le Setup failed…

jrvrcd · Mars 22, 2023, 1:30

je viens de penser a un truc, de memoire pour les cameras ai-thinker il fallait configurer le FTDI en 5 V et non en 3.3

j’ai trouvé cela
https://haade.fr/fr/blog/esp32cam-ai-thinker-homeassistant-esphome-configuration-complete

peut être que cela débloquera la situation

attention c’est pas du code dont je parle
mais de la methodologie qui impose de flasher sous 5V et non 3.3 V
et bien entendu ne pas oublier de repasser ton FTDI a 3.3 sinon … tu vas cramer des choses

BLG · Mars 22, 2023, 6:16

merci pour ton info
lorsque je connecte la carte esp32cam a mon ordinateur, j’alimente directement celle ci par le support qui est équipé d’un Port Micro usb et je suppose quelle est alimentée en 5v

Bob · Mars 22, 2023, 6:49

Bonsoir,
Au départ j’utilisais aussi le FT232RL mais maintenant je trouve bien plus pratique de commander l’ESP-CAM 32 avec le support

Bob

Ldcm · Juin 12, 2023, 4:10

tu utilise cette camera sans probleme? car j’ai erreur Setup Failed: ESP_ERR_NOT_FOUND
