Aldes T.One AIR / AquaAIR

djtef · Janvier 4, 2025, 7:37

Personnellement j’y ai passé plusieurs heures à essayer de faire du reverse engineering sur le binaire du logiciel de mise à jour avec Ghidra. C’est accès compliqué et je ne suis pas spécialiste du domaine, on voit des choses mais c’est pas évident à configurer.
Je me suis juré de jamais payer leur arnaque, surtout que j’en ai deux. Au pire je lancerai la clim à fond avec le mode test.

guix77 · Janvier 4, 2025, 12:14

J’ai payé pour la clim’. Pour le mode ventilation, il est juste présent dans la doc Modbus d’Aldes mais je ne l’ai vu nulle part ailleurs (ni dans la télécommande, ni dans l’app, ni dans toutes les docs et les pages web que j’ai lu).

ji76 · Janvier 4, 2025, 12:34

À c’est pas encourageant, si même toi tu as dû payer …
Pour le mode ventilation, si je comprends bien tu n’as pas réussi à l’activer ?
Merci

ji76 · Janvier 4, 2025, 12:35

Reste t’il des pcb de dispo ?
Sinon qui serait intéressé par une nouvelle commande ?

Thibaut_Fluteaux · Janvier 4, 2025, 1:43

Hello il m’en reste 8.

Hugz · Janvier 5, 2025, 1:19

Hello,

J’ai fait la révision de ma PAC la semaine dernière, et le professionnel, qui a une Tone Aqua chez lui, m’a confirmé qu’il n’y avait pas de « mode ventilation » à proprement parler. Nous avons discuté de l’application Aldes, de la Box AldesConnect, et il semblait satisfait du produit et de ses fonctionnalités. Donc, on ne peut pas lui faire confiance !

Cependant, il existe une manipulation à effectuer sur les thermostats (appui long sur les deux boutons + et -) pour lancer le mode test, qui ne dure que 2 à 3 minutes. La bouche s’ouvre et la soufflerie démarre. Avec cette information, il y aurait peut-être moyen de détourner ce comportement ?

Il me reste également 4 PCB avec la version « basic » (sans l’amélioration des bouches), une solution que j’ai partagée sur le GitHub de @guix77. Ajout du PCB sans bouche
J’ai aussi 4 PCB avec ma solution « advanced » pour ceux qui ont plus de 4 bouches, avec un maximum de 6 bouches (pour correspondre aux pins ADC de l’ESP32).
Pour ceux qui en ont plus, à part avoir un deuxième board et un deuxième ESP32, je n’ai pas de solution…
Quelques images ici de mon post :

De plus, je travaille sur la conception d’un nouveau PCB qui permettra de fusionner les travaux de tout le monde.
Ce PCB intégrera à la fois la récupération des températures des pièces à partir de la commande centrale et la modification des consignes venant de la carte mère.
L’objectif est d’éviter de multiplier les capteurs Aqara/Sonoff dans tout le logement, puisque les thermostats peuvent déjà nous fournir les températures.

À ma connaissance, ce circuit devrait fonctionner.

(110mm*104mm)

Je suis à l’écoute de toute suggestion et amélioration ! J’espère avoir des retours, qu’ils soient positifs ou négatifs, sur ce PCB afin de m’assurer qu’il fonctionne avant de passer la commande.
Nous pouvons envisager de commander plus de 5 PCB si certaines personnes sont intéressées.

PS: PCB fortement inspiré du travail de @guix77
PS2 : Si quelqu’un s’y connaît en conception de pièces 3D, je suis intéressé par la création d’un boîtier sur mesure.

Thibaut_Fluteaux · Janvier 5, 2025, 1:33

Hello, pour la 3d je peux faire, j’ai juste pas eu le temps pendant les fêtes.

Le boitier serait aimanté pour le caller sur les parois du t-one, qu’en pensz vous ?

Hugz · Janvier 5, 2025, 2:16

@Thibaut_Fluteaux Super ! J’ai réussi à mettre un PCB entre le châssis et le « cache avant » détachable, et ça passe en épaisseur. Je l’avais mis dans la pochette avec la vignette DPE .
Avec une boîte imprimée en 3D, je ne sais pas si ça passe encore. Ou alors, on fait un trou dans le châssis sur le dessus…
@guix77 @djtef, vous l’avez installé comment, vous ?

En complément de mon précédent post, il faut bien évidemment modifier la configuration YAML dans ESPHome pour spécifier que l’ESP32 aura deux sources Modbus. Je ne sais pas si c’est réellement possible, mais notre ami le chat j’ai pété m’a proposé quelque chose que j’ai adapté comme suit :

exemple:

#dans le cas ou j'ai deux input, commande centrale et carte mère
uart:
  - id: uart_motherboard
    baud_rate: 19200
    tx_pin: GPIO16
    rx_pin: GPIO17
    parity: EVEN

  - id: uart_central_command
    baud_rate: 19200
    tx_pin: GPIO4
    rx_pin: GPIO5
    parity: EVEN

modbus_controller:
  - id: motherboard
    uart_id: uart_motherboard
    address: 0x1

  - id: central_command
    uart_id: uart_central_command
    address: 0x1

#Exemple d'utilisation
binary_sensor:
  - platform: modbus_controller
    modbus_controller_id: motherboard
    name: "Changer filtre"
    device_class: problem
    entity_category: diagnostic
    icon: mdi:air-filter
    register_type: holding
    address: 0x0082

sensor:
  - platform: modbus_controller
    modbus_controller_id: motherboard
    name: "Temperature principale"
    device_class: temperature
    state_class: measurement
    register_type: holding
    address: 0x0078
    value_type: S_WORD
    unit_of_measurement: "°C"
    accuracy_decimals: 1
    filters:
      - multiply: 0.01

  - platform: modbus_controller
    modbus_controller_id: central_command
    name: "Temperature K1a"
    device_class: temperature
    state_class: measurement
    register_type: holding
    address: 190
    value_type: S_WORD
    unit_of_measurement: "°C"
    accuracy_decimals: 1
    filters:
      - multiply: 0.01

Des experts d’ESPHome ?

guix77 · Janvier 5, 2025, 2:34

Le mode peut très bien figurer dans le Modbus juste pour renvoyer l’état ventilation lors du test… Vu que ça ne marche pas quand on met ce mode via la Modbus, je doute qu’on y arrive par un autre moyen. Ca promet d’être hasardeux et compliqué. Mais si quelqu’un y arrive, chapeau. Après, pour mettre en perspective : chez moi au RDC j’ai une PAC Airzone et j’ai en plus le mode ventilation et le mode déshumidification. Concrètement, à part pour tester, je ne les utilise pas…

Top ! Si tu veux un retour, mets plutôt le schéma qui est plus simple à lire. Il y a un problème potentiel au niveau de la largeur des pistes 5V qui pourrait être insuffisante pour l’intensité. Ce problème était déjà là sur mon PCB mais la différence me semblait suffisamment faible. Là tu ajoutes en conso max 100mA pour le 2ème TTL/RS485 et 10 mA pour 2ème convertisseur des bouches. Ca reste probablement acceptable vu qu’on ne travaille normalement pas en conso max, mais je préfère soulever le sujet quand même. Ci-dessous les « calculs » que j’avais fait pour mon PCB:

guix77 · Janvier 5, 2025, 2:44

Photo ?

Ca pend et j’ai toujours pas remis la télécommande et le cache lol… J’ai pas le temps / la motivation suffisante pour finaliser proprement

Il vaudrait mieux que tu testes d’abord en mode breadboard. Là ton 2ème UART n’est pas hardware. J’utiliserais plutôt GPIO1 (RX) et GPIO3 (TX) qui sont UART hardware. Cf ton schéma de pinout : https://cdn.shopify.com/s/files/1/1509/1638/files/D1_Mini_ESP32_-_pinout.pdf?v=1604068668

Le reste du YAML a l’air OK mais encore une fois à tester avant d’imprimer le PCB

Hugz · Janvier 5, 2025, 4:01

Voila, j’ai ajouté le nouveau modBus de la commande centrale en bas, que j’ai relié avec les ports de liaison pour pas tout refaire. J’ai utilisé les deux voix du level shifter restantes pour les deux nouveaux TXD et RXD que j’ai donc relié aux TXD (GPIO3) et RXD (GPIO1) de l’ESP32

J’avais déjà pris en compte ta remarque, et j’avais augmenté à 0,3mm sur l’ensemble des pistes du PCB. A voir si il faut encore augmenter…

J’ai tout enlevé lors de la venue du chauffagiste et je n’ai pas encore tout remis en place. Mais si tu regardes la photo que je t’avais envoyée, tu verras que j’ai simplement plié les fils pour qu’ils passent dans l’encoche prévue pour le câble de la commande centrale, et j’ai mis le PCB dans la pochette qu’on voit
Je ne pense pas qu’on puisse faire la même chose avec les 4 à 6 câbles des bouches…

Je ne sais pas ce que cela signifie.

C’est ce que j’ai fait, ou du moins essayé… GPIO1 (RX) et GPIO3 (TX). Je me suis peut-être trompé ?

Hugz · Janvier 5, 2025, 4:04

fichier EasyEAD:

{
  "editorVersion": "6.5.47",
  "docType": "5",
  "title": "ESPHome Aldes T.One central command v3",
  "description": "",
  "colors": {},
  "schematics": [
    {
      "docType": "1",
      "title": "ESPHome Aldes T.One - central command v3",
      "description": "",
      "dataStr": {
        "head": {
          "docType": "1",
          "editorVersion": "6.5.47",
          "newgId": true,
          "c_para": {
            "Prefix Start": "1"
          },
          "c_spiceCmd": "null",
          "hasIdFlag": true,
          "uuid": "bc7d39d5e2f9441787b486c03adce1b6",
          "x": "0",
          "y": "0",
          "portOfADImportHack": "",
          "importFlag": 0,
          "transformList": ""
        },
        "canvas": "CA~1000~1000~#FFFFFF~yes~#CCCCCC~5~1000~1000~line~5~pixel~5~0~0",
        "shape": [
          "W~725 -625 650 -625 650 -580 520 -580~#FF00FF~1~0~none~gge358~0",
          "W~520 -590 565 -590 565 -585 575 -585~#FF00FF~1~0~none~gge361~0",
          "W~575 -605 550 -605 550 -655 520 -655~#FF00FF~1~0~none~gge364~0",
          "W~520 -665 560 -665 560 -625 575 -625~#FF00FF~1~0~none~gge367~0",
          "W~575 -645 565 -645 565 -675 520 -675~#FF00FF~1~0~none~gge370~0",
          "W~520 -685 535 -685 535 -700 570 -700 570 -655 575 -655~#FF00FF~1~0~none~gge373~0",
          "W~320 -435 320 -420 395 -420 395 -590 400 -590~#000000~1~0~none~gge376~0",
          "W~320 -445 320 -460 390 -460 390 -600 400 -600~#FF0000~1~0~none~gge379~0",
          "W~320 -485 320 -470 385 -470 385 -610 400 -610~#000000~1~0~none~gge382~0",
          "W~320 -495 320 -510 380 -510 380 -620 400 -620~#FF0000~1~0~none~gge385~0",
          "W~320 -535 320 -520 375 -520 375 -635 385 -635 385 -645 400 -645~#000000~1~0~none~gge388~0",
          "W~320 -545 320 -560 370 -560 370 -640 380 -640 380 -655 400 -655~#FF0000~1~0~none~gge391~0",
          "W~320 -585 320 -570 365 -570 365 -645 375 -645 375 -665 400 -665~#000000~1~0~none~gge394~0",
          "W~320 -595 320 -610 360 -610 360 -650 370 -650 370 -675 400 -675~#FF0000~1~0~none~gge397~0",
          "W~320 -635 320 -620 355 -620 355 -655 365 -655 365 -685 400 -685~#000000~1~0~none~gge400~0",
          "W~520 -600 545 -600~#000000~1~0~none~gge403~0",
          "W~520 -695 545 -695 545 -685~#000000~1~0~none~gge406~0",
          "W~320 -645 320 -660 360 -660 360 -695 400 -695~#FF0000~1~0~none~gge409~0",
          "W~320 -685 320 -670 355 -670 355 -705 400 -705~#000000~1~0~none~gge412~0",
          "W~320 -695 320 -710 400 -710 400 -715~#FF0000~1~0~none~gge415~0",
          "W~520 -705 555 -705 555 -610~#FF0000~1~0~none~gge418~0",
          "W~520 -610 555 -610 555 -535~#FF0000~1~0~none~gge421~0",
          "LIB~460~-585~package`OP71`Manufacturer``Manufacturer Part``Supplier Part``Supplier`Ali`link``Contributor`jirwald`spicePre`U`spiceSymbolName`OP71A04_KYT_by_Gyu`~~0~gge5699bb342837daf6~18054035d6b54001b9569adb10d0611e~a7df9777ae8545b18e934fe02147d069~0~~yes~yes~50410f8abbf54079882afeeb573552f9~1697915698~1cd8af28bd3b406abe40cafe79713554#@$T~N~454.25~-633~0~#000080~Arial~~~~~comment~OP71A04_KYT_by_Gyu~0~start~gge430~0~#@$T~P~456.25~-642~0~#000080~Arial~~~~~comment~U14~0~start~gge436~0~#@$R~410~-630~2~2~100~90~#880000~1~0~none~gge442~0~#@$E~415~-625~1.5~1.5~#880000~1~0~#880000~gge445~0#@$P~show~0~1~400~-620~180~gge448~0^^400~-620^^M 400 -620 h 10~#880000^^1~413.7~-616~0~1+~start~~~#0000FF^^1~409.5~-621~0~1~end~~~#0000FF^^0~407~-620^^0~M 410 -617 L 413 -620 L 410 -623#@$P~show~0~2~400~-610~180~gge469~0^^400~-610^^M 400 -610 h 10~#880000^^1~413.7~-606~0~1-~start~~~#0000FF^^1~409.5~-611~0~2~end~~~#0000FF^^0~407~-610^^0~M 410 -607 L 413 -610 L 410 -613#@$P~show~0~3~400~-600~180~gge490~0^^400~-600^^M 400 -600 h 10~#880000^^1~413.7~-596~0~2+~start~~~#0000FF^^1~409.5~-601~0~3~end~~~#0000FF^^0~407~-600^^0~M 410 -597 L 413 -600 L 410 -603#@$P~show~0~4~400~-590~180~gge511~0^^400~-590^^M 400 -590 h 10~#880000^^1~413.7~-586~0~2-~start~~~#0000FF^^1~409.5~-591~0~4~end~~~#0000FF^^0~407~-590^^0~M 410 -587 L 413 -590 L 410 -593#@$P~show~0~5~400~-580~180~gge532~0^^400~-580^^M 400 -580 h 10~#880000^^1~413.7~-576~0~3+~start~~~#0000FF^^1~409.5~-581~0~5~end~~~#0000FF^^0~407~-580^^0~M 410 -577 L 413 -580 L 410 -583#@$P~show~0~6~400~-570~180~gge553~0^^400~-570^^M 400 -570 h 10~#880000^^1~413.7~-566~0~3-~start~~~#0000FF^^1~409.5~-571~0~6~end~~~#0000FF^^0~407~-570^^0~M 410 -567 L 413 -570 L 410 -573#@$P~show~0~7~400~-560~180~gge574~0^^400~-560^^M 400 -560 h 10~#880000^^1~413.7~-556~0~4+~start~~~#0000FF^^1~409.5~-561~0~7~end~~~#0000FF^^0~407~-560^^0~M 410 -557 L 413 -560 L 410 -563#@$P~show~0~8~400~-550~180~gge595~0^^400~-550^^M 400 -550 h 10~#880000^^1~413.7~-546~0~4-~start~~~#0000FF^^1~409.5~-551~0~8~end~~~#0000FF^^0~407~-550^^0~M 410 -547 L 413 -550 L 410 -553#@$P~show~0~10~520~-560~0~gge616~0^^520~-560^^M 520 -560 h -10~#880000^^1~506.3~-556~0~04~end~~~#0000FF^^1~510.5~-561~0~9~start~~~#0000FF^^0~513~-560^^0~M 510 -563 L 507 -560 L 510 -557#@$P~show~0~11~520~-570~0~gge637~0^^520~-570^^M 520 -570 h -10~#880000^^1~506.3~-566~0~03~end~~~#0000FF^^1~510.5~-571~0~10~start~~~#0000FF^^0~513~-570^^0~M 510 -573 L 507 -570 L 510 -567#@$P~show~0~12~520~-580~0~gge658~0^^520~-580^^M 520 -580 h -10~#880000^^1~506.3~-576~0~02~end~~~#0000FF^^1~510.5~-581~0~11~start~~~#0000FF^^0~513~-580^^0~M 510 -583 L 507 -580 L 510 -577#@$P~show~0~13~520~-590~0~gge679~0^^520~-590^^M 520 -590 h -10~#880000^^1~506.3~-586~0~01~end~~~#0000FF^^1~510.5~-591~0~12~start~~~#0000FF^^0~513~-590^^0~M 510 -593 L 507 -590 L 510 -587#@$P~show~0~14~520~-600~0~gge700~0^^520~-600^^M 520 -600 h -10~#880000^^1~506.3~-596~0~GND~end~~~#0000FF^^1~510.5~-601~0~13~start~~~#0000FF^^0~513~-600^^0~M 510 -603 L 507 -600 L 510 -597#@$P~show~0~15~520~-610~0~gge721~0^^520~-610^^M 520 -610 h -10~#880000^^1~506.3~-606~0~VCC~end~~~#0000FF^^1~510.5~-611~0~14~start~~~#0000FF^^0~513~-610^^0~M 510 -613 L 507 -610 L 510 -607#@$T~L~445~-585~0~#0000FF~~9pt~~~~comment~OP71~1~start~gge742~0~pinpart#@$T~L~450~-575~0~#0000FF~~9pt~~~~comment~A04~1~start~gge748~0~pinpart",
          "LIB~460~-680~package`OP71`Manufacturer``Manufacturer Part``Supplier Part``Supplier`Ali`link``Contributor`jirwald`spicePre`U`spiceSymbolName`OP71A04_KYT_by_Gyu`~~0~gge8a6ca2dc726d3720~18054035d6b54001b9569adb10d0611e~a7df9777ae8545b18e934fe02147d069~0~~yes~yes~50410f8abbf54079882afeeb573552f9~1697915698~1cd8af28bd3b406abe40cafe79713554#@$T~N~444.42~-726.67~0~#000080~Arial~~~~~comment~OP71A04_KYT_by_Gyu~1~start~gge760~0~#@$T~P~429.03~-726.67~0~#000080~Arial~~~~~comment~U7~1~start~gge766~0~#@$R~410~-725~2~2~100~90~#880000~1~0~none~gge772~0~#@$E~415~-720~1.5~1.5~#880000~1~0~#880000~gge775~0#@$P~show~0~1~400~-715~180~gge778~0^^400~-715^^M 400 -715 h 10~#880000^^1~413.7~-711~0~1+~start~~~#0000FF^^1~409.5~-716~0~1~end~~~#0000FF^^0~407~-715^^0~M 410 -712 L 413 -715 L 410 -718#@$P~show~0~2~400~-705~180~gge799~0^^400~-705^^M 400 -705 h 10~#880000^^1~413.7~-701~0~1-~start~~~#0000FF^^1~409.5~-706~0~2~end~~~#0000FF^^0~407~-705^^0~M 410 -702 L 413 -705 L 410 -708#@$P~show~0~3~400~-695~180~gge820~0^^400~-695^^M 400 -695 h 10~#880000^^1~413.7~-691~0~2+~start~~~#0000FF^^1~409.5~-696~0~3~end~~~#0000FF^^0~407~-695^^0~M 410 -692 L 413 -695 L 410 -698#@$P~show~0~4~400~-685~180~gge841~0^^400~-685^^M 400 -685 h 10~#880000^^1~413.7~-681~0~2-~start~~~#0000FF^^1~409.5~-686~0~4~end~~~#0000FF^^0~407~-685^^0~M 410 -682 L 413 -685 L 410 -688#@$P~show~0~5~400~-675~180~gge862~0^^400~-675^^M 400 -675 h 10~#880000^^1~413.7~-671~0~3+~start~~~#0000FF^^1~409.5~-676~0~5~end~~~#0000FF^^0~407~-675^^0~M 410 -672 L 413 -675 L 410 -678#@$P~show~0~6~400~-665~180~gge883~0^^400~-665^^M 400 -665 h 10~#880000^^1~413.7~-661~0~3-~start~~~#0000FF^^1~409.5~-666~0~6~end~~~#0000FF^^0~407~-665^^0~M 410 -662 L 413 -665 L 410 -668#@$P~show~0~7~400~-655~180~gge904~0^^400~-655^^M 400 -655 h 10~#880000^^1~413.7~-651~0~4+~start~~~#0000FF^^1~409.5~-656~0~7~end~~~#0000FF^^0~407~-655^^0~M 410 -652 L 413 -655 L 410 -658#@$P~show~0~8~400~-645~180~gge925~0^^400~-645^^M 400 -645 h 10~#880000^^1~413.7~-641~0~4-~start~~~#0000FF^^1~409.5~-646~0~8~end~~~#0000FF^^0~407~-645^^0~M 410 -642 L 413 -645 L 410 -648#@$P~show~0~10~520~-655~0~gge946~0^^520~-655^^M 520 -655 h -10~#880000^^1~506.3~-651~0~04~end~~~#0000FF^^1~510.5~-656~0~9~start~~~#0000FF^^0~513~-655^^0~M 510 -658 L 507 -655 L 510 -652#@$P~show~0~11~520~-665~0~gge967~0^^520~-665^^M 520 -665 h -10~#880000^^1~506.3~-661~0~03~end~~~#0000FF^^1~510.5~-666~0~10~start~~~#0000FF^^0~513~-665^^0~M 510 -668 L 507 -665 L 510 -662#@$P~show~0~12~520~-675~0~gge988~0^^520~-675^^M 520 -675 h -10~#880000^^1~506.3~-671~0~02~end~~~#0000FF^^1~510.5~-676~0~11~start~~~#0000FF^^0~513~-675^^0~M 510 -678 L 507 -675 L 510 -672#@$P~show~0~13~520~-685~0~gge1009~0^^520~-685^^M 520 -685 h -10~#880000^^1~506.3~-681~0~01~end~~~#0000FF^^1~510.5~-686~0~12~start~~~#0000FF^^0~513~-685^^0~M 510 -688 L 507 -685 L 510 -682#@$P~show~0~14~520~-695~0~gge1030~0^^520~-695^^M 520 -695 h -10~#880000^^1~506.3~-691~0~GND~end~~~#0000FF^^1~510.5~-696~0~13~start~~~#0000FF^^0~513~-695^^0~M 510 -698 L 507 -695 L 510 -692#@$P~show~0~15~520~-705~0~gge1051~0^^520~-705^^M 520 -705 h -10~#880000^^1~506.3~-701~0~VCC~end~~~#0000FF^^1~510.5~-706~0~14~start~~~#0000FF^^0~513~-705^^0~M 510 -708 L 507 -705 L 510 -702#@$T~L~445~-680~0~#0000FF~~9pt~~~~comment~OP71~1~start~gge1072~0~pinpart#@$T~L~450~-670~0~#0000FF~~9pt~~~~comment~A04~1~start~gge1078~0~pinpart",
          "LIB~650~-605~package`AZDELIVERYD1 ESP32 MINI`Manufacturer`AzDelivery`Manufacturer Part`D1 Mini ESP32`Supplier`AzDelivery`Supplier Part`D1 mini ESP32`link`https://www.az-delivery.de/nl/products/esp32-d1-mini`Contributor`Jelke`spicePre`U`spiceSymbolName`AzDelivery D1 ESP32 Mini`~~0~gge48695d9ba1ce7d12~c4bfddb9118a4280aa7751241de8caaa~5f62706d12ec4146a1c20c4ef295946c~0~~yes~yes~b1cd8c972f9040609c19f01c920076ba~1717407520~d637cf026c1044b0bc58e124d47fb3a3#@$T~N~642.14~-728~0~#000080~Arial~~~~~comment~AzDelivery D1 ESP32 Mini~1~start~gge1090~0~#@$T~P~643.57~-737.14~0~#000080~Arial~~~~~comment~U6~1~start~gge1096~0~#@$P~show~0~1~575~-685~180~gge1102~0^^575~-685^^M 575 -685 h 20~#880000^^1~597~-682~0~GND~start~~~#0000FF^^1~590~-686~0~1~end~~~#0000FF^^0~592~-685^^0~M 595 -682 L 598 -685 L 595 -688#@$P~show~0~2~575~-665~180~gge1123~0^^575~-665^^M 575 -665 h 20~#880000^^1~597~-662~0~NC~start~~~#0000FF^^1~590~-666~0~2~end~~~#0000FF^^0~592~-665^^0~M 595 -662 L 598 -665 L 595 -668#@$P~show~0~3~575~-645~180~gge1144~0^^575~-645^^M 575 -645 h 20~#880000^^1~597~-642~0~SUN~start~~~#0000FF^^1~590~-646~0~3~end~~~#0000FF^^0~592~-645^^0~M 595 -642 L 598 -645 L 595 -648#@$P~show~0~4~575~-625~180~gge1165~0^^575~-625^^M 575 -625 h 20~#880000^^1~597~-622~0~IO35~start~~~#0000FF^^1~590~-626~0~4~end~~~#0000FF^^0~592~-625^^0~M 595 -622 L 598 -625 L 595 -628#@$P~show~0~5~575~-605~180~gge1186~0^^575~-605^^M 575 -605 h 20~#880000^^1~597~-602~0~IO33~start~~~#0000FF^^1~590~-606~0~5~end~~~#0000FF^^0~592~-605^^0~M 595 -602 L 598 -605 L 595 -608#@$P~show~0~6~575~-585~180~gge1207~0^^575~-585^^M 575 -585 h 20~#880000^^1~597~-582~0~IO34~start~~~#0000FF^^1~590~-586~0~6~end~~~#0000FF^^0~592~-585^^0~M 595 -582 L 598 -585 L 595 -588#@$P~show~0~7~575~-565~180~gge1228~0^^575~-565^^M 575 -565 h 20~#880000^^1~597~-562~0~TMS~start~~~#0000FF^^1~590~-566~0~7~end~~~#0000FF^^0~592~-565^^0~M 595 -562 L 598 -565 L 595 -568#@$P~show~0~8~575~-545~180~gge1249~0^^575~-545^^M 575 -545 h 20~#880000^^1~597~-542~0~NC~start~~~#0000FF^^1~590~-546~0~8~end~~~#0000FF^^0~592~-545^^0~M 595 -542 L 598 -545 L 595 -548#@$P~show~0~9~575~-525~180~gge1270~0^^575~-525^^M 575 -525 h 20~#880000^^1~597~-522~0~SD2~start~~~#0000FF^^1~590~-526~0~9~end~~~#0000FF^^0~592~-525^^0~M 595 -522 L 598 -525 L 595 -528#@$P~show~0~10~575~-505~180~gge1291~0^^575~-505^^M 575 -505 h 20~#880000^^1~597~-502~0~CMD~start~~~#0000FF^^1~590~-506~0~10~end~~~#0000FF^^0~592~-505^^0~M 595 -502 L 598 -505 L 595 -508#@$P~show~0~11~575~-675~180~gge1312~0^^575~-675^^M 575 -675 h 40~#880000^^1~617~-672~0~RST~start~~~#0000FF^^1~590~-676~0~11~end~~~#0000FF^^0~612~-675^^0~M 615 -672 L 618 -675 L 615 -678#@$P~show~0~12~575~-655~180~gge1333~0^^575~-655^^M 575 -655 h 40~#880000^^1~617~-652~0~SUP~start~~~#0000FF^^1~590~-656~0~12~end~~~#0000FF^^0~612~-655^^0~M 615 -652 L 618 -655 L 615 -658#@$P~show~0~13~575~-635~180~gge1354~0^^575~-635^^M 575 -635 h 40~#880000^^1~617~-632~0~IO26~start~~~#0000FF^^1~590~-636~0~13~end~~~#0000FF^^0~612~-635^^0~M 615 -632 L 618 -635 L 615 -638#@$P~show~0~14~575~-615~180~gge1375~0^^575~-615^^M 575 -615 h 40~#880000^^1~617~-612~0~IO18~start~~~#0000FF^^1~590~-616~0~14~end~~~#0000FF^^0~612~-615^^0~M 615 -612 L 618 -615 L 615 -618#@$P~show~0~15~575~-595~180~gge1396~0^^575~-595^^M 575 -595 h 40~#880000^^1~617~-592~0~IO19~start~~~#0000FF^^1~590~-596~0~15~end~~~#0000FF^^0~612~-595^^0~M 615 -592 L 618 -595 L 615 -598#@$P~show~0~16~575~-575~180~gge1417~0^^575~-575^^M 575 -575 h 40~#880000^^1~617~-572~0~IO23~start~~~#0000FF^^1~590~-576~0~16~end~~~#0000FF^^0~612~-575^^0~M 615 -572 L 618 -575 L 615 -578#@$P~show~0~17~575~-555~180~gge1438~0^^575~-555^^M 575 -555 h 40~#880000^^1~617~-552~0~IO5~start~~~#0000FF^^1~590~-556~0~17~end~~~#0000FF^^0~612~-555^^0~M 615 -552 L 618 -555 L 615 -558#@$P~show~0~18~575~-535~180~gge1459~0^^575~-535^^M 575 -535 h 40~#880000^^1~617~-532~0~3.3v~start~~~#0000FF^^1~590~-536~0~18~end~~~#0000FF^^0~612~-535^^0~M 615 -532 L 618 -535 L 615 -538#@$P~show~0~19~575~-515~180~gge1480~0^^575~-515^^M 575 -515 h 40~#880000^^1~617~-512~0~TCK~start~~~#0000FF^^1~590~-516~0~19~end~~~#0000FF^^0~612~-515^^0~M 615 -512 L 618 -515 L 615 -518#@$P~show~0~20~575~-495~180~gge1501~0^^575~-495^^M 575 -495 h 40~#880000^^1~617~-492~0~SD3~start~~~#0000FF^^1~590~-496~0~20~end~~~#0000FF^^0~612~-495^^0~M 615 -492 L 618 -495 L 615 -498#@$P~show~0~21~725~-685~0~gge1522~0^^725~-685^^M 725 -685 h -20~#880000^^1~703~-682~0~GND~end~~~#0000FF^^1~710~-686~0~31~start~~~#0000FF^^0~708~-685^^0~M 705 -688 L 702 -685 L 705 -682#@$P~show~0~22~725~-665~0~gge1543~0^^725~-665^^M 725 -665 h -20~#880000^^1~703~-662~0~IO27~end~~~#0000FF^^1~710~-666~0~32~start~~~#0000FF^^0~708~-665^^0~M 705 -668 L 702 -665 L 705 -662#@$P~show~0~23~725~-645~0~gge1564~0^^725~-645^^M 725 -645 h -20~#880000^^1~703~-642~0~IO25~end~~~#0000FF^^1~710~-646~0~33~start~~~#0000FF^^0~708~-645^^0~M 705 -648 L 702 -645 L 705 -642#@$P~show~0~24~725~-625~0~gge1585~0^^725~-625^^M 725 -625 h -20~#880000^^1~703~-622~0~IO32~end~~~#0000FF^^1~710~-626~0~34~start~~~#0000FF^^0~708~-625^^0~M 705 -628 L 702 -625 L 705 -622#@$P~show~0~25~725~-605~0~gge1606~0^^725~-605^^M 725 -605 h -20~#880000^^1~703~-602~0~TDI~end~~~#0000FF^^1~710~-606~0~35~start~~~#0000FF^^0~708~-605^^0~M 705 -608 L 702 -605 L 705 -602#@$P~show~0~26~725~-585~0~gge1627~0^^725~-585^^M 725 -585 h -20~#880000^^1~703~-582~0~IO4~end~~~#0000FF^^1~710~-586~0~36~start~~~#0000FF^^0~708~-585^^0~M 705 -588 L 702 -585 L 705 -582#@$P~show~0~27~725~-565~0~gge1648~0^^725~-565^^M 725 -565 h -20~#880000^^1~703~-562~0~IO0~end~~~#0000FF^^1~710~-566~0~37~start~~~#0000FF^^0~708~-565^^0~M 705 -568 L 702 -565 L 705 -562#@$P~show~0~28~725~-545~0~gge1669~0^^725~-545^^M 725 -545 h -20~#880000^^1~703~-542~0~IO2~end~~~#0000FF^^1~710~-546~0~38~start~~~#0000FF^^0~708~-545^^0~M 705 -548 L 702 -545 L 705 -542#@$P~show~0~29~725~-525~0~gge1690~0^^725~-525^^M 725 -525 h -20~#880000^^1~703~-522~0~SD1~end~~~#0000FF^^1~710~-526~0~39~start~~~#0000FF^^0~708~-525^^0~M 705 -528 L 702 -525 L 705 -522#@$P~show~0~30~725~-505~0~gge1711~0^^725~-505^^M 725 -505 h -20~#880000^^1~703~-502~0~CLK~end~~~#0000FF^^1~710~-506~0~40~start~~~#0000FF^^0~708~-505^^0~M 705 -508 L 702 -505 L 705 -502#@$P~show~0~31~725~-675~0~gge1732~0^^725~-675^^M 725 -675 h -40~#880000^^1~683~-672~0~Txd~end~~~#0000FF^^1~710~-676~0~21~start~~~#0000FF^^0~688~-675^^0~M 685 -678 L 682 -675 L 685 -672#@$P~show~0~32~725~-655~0~gge1753~0^^725~-655^^M 725 -655 h -40~#880000^^1~683~-652~0~Rxd~end~~~#0000FF^^1~710~-656~0~22~start~~~#0000FF^^0~688~-655^^0~M 685 -658 L 682 -655 L 685 -652#@$P~show~0~33~725~-635~0~gge1774~0^^725~-635^^M 725 -635 h -40~#880000^^1~683~-632~0~IO22~end~~~#0000FF^^1~710~-636~0~23~start~~~#0000FF^^0~688~-635^^0~M 685 -638 L 682 -635 L 685 -632#@$P~show~0~34~725~-615~0~gge1795~0^^725~-615^^M 725 -615 h -40~#880000^^1~683~-612~0~IO21~end~~~#0000FF^^1~710~-616~0~24~start~~~#0000FF^^0~688~-615^^0~M 685 -618 L 682 -615 L 685 -612#@$P~show~0~35~725~-595~0~gge1816~0^^725~-595^^M 725 -595 h -40~#880000^^1~683~-592~0~IO17~end~~~#0000FF^^1~710~-596~0~25~start~~~#0000FF^^0~688~-595^^0~M 685 -598 L 682 -595 L 685 -592#@$P~show~0~36~725~-575~0~gge1837~0^^725~-575^^M 725 -575 h -40~#880000^^1~683~-572~0~IO16~end~~~#0000FF^^1~710~-576~0~26~start~~~#0000FF^^0~688~-575^^0~M 685 -578 L 682 -575 L 685 -572#@$P~show~0~37~725~-555~0~gge1858~0^^725~-555^^M 725 -555 h -40~#880000^^1~683~-552~0~GND~end~~~#0000FF^^1~710~-556~0~27~start~~~#0000FF^^0~688~-555^^0~M 685 -558 L 682 -555 L 685 -552#@$P~show~0~38~725~-535~0~gge1879~0^^725~-535^^M 725 -535 h -40~#880000^^1~683~-532~0~VCC~end~~~#0000FF^^1~710~-536~0~28~start~~~#0000FF^^0~688~-535^^0~M 685 -538 L 682 -535 L 685 -532#@$P~show~0~39~725~-515~0~gge1900~0^^725~-515^^M 725 -515 h -40~#880000^^1~683~-512~0~TD0~end~~~#0000FF^^1~710~-516~0~29~start~~~#0000FF^^0~688~-515^^0~M 685 -518 L 682 -515 L 685 -512#@$P~show~0~40~725~-495~0~gge1921~0^^725~-495^^M 725 -495 h -40~#880000^^1~683~-492~0~SDD~end~~~#0000FF^^1~710~-496~0~30~start~~~#0000FF^^0~688~-495^^0~M 685 -498 L 682 -495 L 685 -492#@$R~595~-695~~~110~205~#000000~1~0~none~gge1942~0~#@$PL~610 -720 610 -700 625 -700 625 -720 640 -720 640 -700 655 -700 655 -720 670 -720 670 -700 685 -700 685 -720~#000000~1~0~none~gge1945~0#@$R~605~-725~~~85~30~#000000~1~0~none~gge1948~0~",
          "LIB~615~-385~package`UART-TTL-RS485. V2`Manufacturer``Manufacturer Part``Supplier Part``Supplier``link``Contributor`Compesalogger`spicePre`U`spiceSymbolName`UART-TTL-RS485_HW-519`~180~0~gge861044c4f3b243c5~a58176efddf245e39b56214be2bba8af~14d4e9a8b2d848bcaaae66a37d5ab510~0~~yes~yes~f0253c41cbd14a72bb146076879619c8~1692093619~4392aeb98460419fae1830a3f532e153#@$T~N~512.33~-441.75~0~#000080~Arial~~~~~comment~UART-TTL-RS485_HW-519~1~start~gge1957~0~#@$T~P~494.03~-441.75~0~#000080~Arial~~~~~comment~U5~1~start~gge1963~0~#@$P~show~0~1~625~-395~0~gge1969~0^^625~-395^^M 625 -395 h -20~#880000^^1~603~-392~0~VCC~end~~6.5pt~#0000FF^^1~610~-396~0~1~start~~6.5pt~#0000FF^^0~608~-395^^0~M 605 -398 L 602 -395 L 605 -392#@$P~show~0~2~625~-405~0~gge1990~0^^625~-405^^M 625 -405 h -20~#880000^^1~603~-402~0~TXD~end~~6.5pt~#0000FF^^1~610~-406~0~2~start~~6.5pt~#0000FF^^0~608~-405^^0~M 605 -408 L 602 -405 L 605 -402#@$P~show~0~3~625~-415~0~gge2011~0^^625~-415^^M 625 -415 h -20~#880000^^1~603~-412~0~RXD~end~~6.5pt~#0000FF^^1~610~-416~0~3~start~~6.5pt~#0000FF^^0~608~-415^^0~M 605 -418 L 602 -415 L 605 -412#@$P~show~0~4~625~-425~0~gge2032~0^^625~-425^^M 625 -425 h -20~#880000^^1~603~-422~0~GND~end~~6.5pt~#0000FF^^1~610~-426~0~4~start~~6.5pt~#0000FF^^0~608~-425^^0~M 605 -428 L 602 -425 L 605 -422#@$P~show~0~5~495~-425~180~gge2053~0^^495~-425^^M 495 -425 h 20~#880000^^1~517~-422~0~GND~start~~6.5pt~#0000FF^^1~510~-426~0~5~end~~6.5pt~#0000FF^^0~512~-425^^0~M 515 -422 L 518 -425 L 515 -428#@$P~show~0~6~495~-405~180~gge2074~0^^495~-405^^M 495 -405 h 20~#880000^^1~517~-402~0~B-~start~~6.5pt~#0000FF^^1~510~-406~0~6~end~~6.5pt~#0000FF^^0~512~-405^^0~M 515 -402 L 518 -405 L 515 -408#@$P~show~0~7~495~-395~180~gge2095~0^^495~-395^^M 495 -395 h 20~#880000^^1~517~-392~0~A+~start~~6.5pt~#0000FF^^1~510~-396~0~7~end~~6.5pt~#0000FF^^0~512~-395^^0~M 515 -392 L 518 -395 L 515 -398#@$R~515~-435~5~5~90~50~#990000~1~0~none~gge2116~0~#@$T~L~542.5~-389~0~#990000~~5.5pt~~~~comment~HW-519~1~start~gge2119~0~pinpart#@$T~L~532~-399~0~#990000~~5.5pt~~~~comment~AutoDetect~1~start~gge2125~0~pinpart",
          "LIB~545~-275~package`DC-DC-STEP-DOWN-MP1584`Manufacturer``Manufacturer Part``Supplier Part``Supplier``link``Contributor`karel.slavicek`spicePre`P`spiceSymbolName`DC-DC-MP1584-5V`~~0~gge5afe9426fc185b58~245aaa693c374c2e8cb26850f8256a80~bbddec229066427aafae1bf21ffd8109~0~~yes~yes~592e4c7b10354db6b35a501e7fe46b08~1658845937~3c45df8fbd074a81918c03d8e74a7cd8#@$T~N~535~-318~0~#000080~Arial~~~~~comment~DC-DC-MP1584-5V~1~start~gge2137~0~#@$T~P~537~-327~0~#000080~Arial~~~~~comment~PWR2~1~start~gge2143~0~#@$T~L~535~-255~0~#0000FF~~9pt~undefined~undefined~~comment~5V~1~start~gge2149~0~pinpart#@$T~L~525~-275~0~#0000FF~~9pt~undefined~undefined~~comment~MP1584~1~start~gge2155~0~pinpart#@$P~show~0~OUT+.1~625~-245~~gge2161~0^^625~-245^^M 625 -245 h -20~#880000^^1~603~-242~0~OUT +~end~~~#0000FF^^1~610~-246~0~OUT+.1~start~~~#0000FF^^0~608~-245^^0~M 605 -248 L 602 -245 L 605 -242#@$P~show~0~OUT+.2~625~-255~~gge2182~0^^625~-255^^M 625 -255 h -20~#880000^^1~603~-252~0~OUT +~end~~~#0000FF^^1~610~-256~0~OUT+.2~start~~~#0000FF^^0~608~-255^^0~M 605 -258 L 602 -255 L 605 -252#@$P~show~0~OUT-.1~625~-295~~gge2203~0^^625~-295^^M 625 -295 h -20~#880000^^1~603~-292~0~OUT -~end~~~#0000FF^^1~610~-296~0~OUT-.1~start~~~#0000FF^^0~608~-295^^0~M 605 -298 L 602 -295 L 605 -292#@$P~show~0~OUT-.2~625~-305~~gge2224~0^^625~-305^^M 625 -305 h -20~#880000^^1~603~-302~0~OUT -~end~~~#0000FF^^1~610~-306~0~OUT-.2~start~~~#0000FF^^0~608~-305^^0~M 605 -308 L 602 -305 L 605 -302#@$P~show~0~IN+.1~465~-245~180~gge2245~0^^465~-245^^M 465 -245 h 20~#880000^^1~487~-242~0~IN +~start~~~#0000FF^^1~480~-246~0~IN+.1~end~~~#0000FF^^0~482~-245^^0~M 485 -242 L 488 -245 L 485 -248#@$P~show~0~IN+.2~465~-255~180~gge2266~0^^465~-255^^M 465 -255 h 20~#880000^^1~487~-252~0~IN +~start~~~#0000FF^^1~480~-256~0~IN+.2~end~~~#0000FF^^0~482~-255^^0~M 485 -252 L 488 -255 L 485 -258#@$P~show~0~IN-.1~465~-295~180~gge2287~0^^465~-295^^M 465 -295 h 20~#880000^^1~487~-292~0~IN -~start~~~#0000FF^^1~480~-296~0~IN-.1~end~~~#0000FF^^0~482~-295^^0~M 485 -292 L 488 -295 L 485 -298#@$P~show~0~IN-.2~465~-305~180~gge2308~0^^465~-305^^M 465 -305 h 20~#880000^^1~487~-302~0~IN -~start~~~#0000FF^^1~480~-306~0~IN-.2~end~~~#0000FF^^0~482~-305^^0~M 485 -302 L 488 -305 L 485 -308#@$T~L~525~-295~0~#0000FF~~9pt~~~~comment~DC-DC~1~start~gge2329~0~pinpart#@$R~485~-315~~~120~80~#000000~1~0~none~gge2335~0~",
          "LIB~350~-315~package`KF301-4P`Manufacturer Part`KF301`Contributor`Slape_tex`spicePre`U`spiceSymbolName`KF301-4P`~270~0~ggeacdc0f1af8cc04c1~67e62fa529da40d7881fddd94d961dc1~298961acd3704ab88b8350683c41d7ec~0~~yes~yes~~1581027284~#@$T~N~340.05~-360~0~#000080~Arial~~~~~comment~KF301-4P~1~start~gge2344~0~#@$T~P~342.05~-369~0~#000080~Arial~~~~~comment~U4~1~start~gge2350~0~#@$PL~340 -355 340 -275.06 370.1 -275.1 370 -355 340 -355 340 -355~#880000~1~0~none~gge2356~0#@$E~353.1~-344.83~6.4~6.54~#880000~1~0~none~gge2359~0#@$E~365.5~-345.0625~1.625~1.5625~#880000~1~0~none~gge2362~0#@$PL~363.3 -355 363.3 -274.7~#880000~1~0~none~gge2365~0#@$PL~343.75 -355 343.7 -275~#880000~1~0~none~gge2368~0#@$E~353.1~-324.95~6.4~6.54~#880000~1~0~none~gge2371~0#@$E~365.495~-325.1825~1.625~1.5625~#880000~1~0~none~gge2374~0#@$R~363.78~-277~~~2.22~1.56~#880000~1~0~none~gge2377~0~#@$R~363.67~-357~~~2.33~1.6~#880000~1~0~none~gge2380~0~#@$P~show~0~1~330~-345~180~gge2383~0^^330~-345^^M 330 -345 h 10~#800000^^0~343~-342~0~1~start~~~#800000^^0~339~-346~0~1~end~~~#800000^^0~337~-345^^0~M 340 -342 L 343 -345 L 340 -348#@$P~show~0~2~330~-325~180~gge2404~0^^330~-325^^M 330 -325 h 10~#800000^^0~343~-322~0~2~start~~~#800000^^0~339~-326~0~2~end~~~#800000^^0~337~-325^^0~M 340 -322 L 343 -325 L 340 -328#@$E~353~-305~6.4~6.54~#880000~1~0~none~gge2425~0#@$E~365.31~-305.08~1.625~1.5625~#880000~1~0~none~gge2428~0#@$P~show~0~3~330~-305~180~gge2431~0^^330~-305^^M 330 -305 h 10~#800000^^0~343~-302~0~3~start~~~#800000^^0~339~-306~0~3~end~~~#800000^^0~337~-305^^0~M 340 -302 L 343 -305 L 340 -308#@$P~show~0~4~330~-285~180~gge2452~0^^330~-285^^M 330 -285 h 10~#800000^^0~343~-282~0~4~start~~~#800000^^0~339~-286~0~4~end~~~#800000^^0~337~-285^^0~M 340 -282 L 343 -285 L 340 -288#@$E~353.2~-284.96~6.4~6.54~#880000~1~0~none~gge2473~0#@$E~365.16~-285.07~1.625~1.5625~#880000~1~0~none~gge2476~0",
          "LIB~780~-429~package`LEVEL-SHIFTER-4CH`Contributor`Dimitri Chiminello`spicePre`?`spiceSymbolName`LEVEL-SHIFTER-4CH`Manufacturer Part``~180~0~gge3b1c614f43f7015a~eda7894c9907422e904deb8a4b58560e~f63cdfd8cf0d441bb432ef7ee5064766~0~~yes~yes~~1587585055~#@$T~N~748.0625~-466.75~0~#000080~Arial~~~~~comment~LEVEL-SHIFTER-4CH~1~start~gge2485~0~#@$T~P~742.4~-466.75~0~#000080~Arial~~~~~comment~2~1~start~gge2491~0~#@$P~show~3~J1.5~840~-445~0~gge2497~0^^840~-445^^M 840 -445 h -19.685~#A54B4B^^1~810.79~-442.047~0~LV3~end~~4.5pt~#A54B4B^^1~832.44~-446.97~0~J1.5~start~~4.5pt~#A54B4B^^0~824~-445^^0~M 821 -448 L 818 -445 L 821 -442#@$P~show~3~J1.4~840~-435~0~gge2518~0^^840~-435^^M 840 -435 h -19.685~#A54B4B^^1~810.79~-432.047~0~GND.1~end~~4.5pt~#A54B4B^^1~832.44~-436.97~0~J1.4~start~~4.5pt~#A54B4B^^0~824~-435^^0~M 821 -438 L 818 -435 L 821 -432#@$P~show~3~J1.3~840~-425~0~gge2539~0^^840~-425^^M 840 -425 h -19.685~#A54B4B^^1~810.79~-422.047~0~LV~end~~4.5pt~#A54B4B^^1~832.44~-426.97~0~J1.3~start~~4.5pt~#A54B4B^^0~824~-425^^0~M 821 -428 L 818 -425 L 821 -422#@$P~show~3~J1.2~840~-415~0~gge2560~0^^840~-415^^M 840 -415 h -19.685~#A54B4B^^1~810.79~-412.047~0~LV2~end~~4.5pt~#A54B4B^^1~832.44~-416.97~0~J1.2~start~~4.5pt~#A54B4B^^0~824~-415^^0~M 821 -418 L 818 -415 L 821 -412#@$P~show~3~J1.1~840~-405~0~gge2581~0^^840~-405^^M 840 -405 h -19.685~#A54B4B^^1~810.79~-402.047~0~LV1~end~~4.5pt~#A54B4B^^1~832.44~-406.97~0~J1.1~start~~4.5pt~#A54B4B^^0~824~-405^^0~M 821 -408 L 818 -405 L 821 -402#@$P~show~3~J2.6~720~-455~180~gge2602~0^^720~-455^^M 720 -455 h 19.685~#A54B4B^^1~749.84~-452.047~0~HV4~start~~4.5pt~#A54B4B^^1~728.19~-456.97~0~J2.6~end~~4.5pt~#A54B4B^^0~736~-455^^0~M 739 -452 L 742 -455 L 739 -458#@$P~show~3~J2.5~720~-445~180~gge2623~0^^720~-445^^M 720 -445 h 19.685~#A54B4B^^1~749.84~-442.047~0~HV3~start~~4.5pt~#A54B4B^^1~728.19~-446.97~0~J2.5~end~~4.5pt~#A54B4B^^0~736~-445^^0~M 739 -442 L 742 -445 L 739 -448#@$P~show~3~J2.4~720~-435~180~gge2644~0^^720~-435^^M 720 -435 h 19.685~#A54B4B^^1~749.84~-432.047~0~GND.2~start~~4.5pt~#A54B4B^^1~728.19~-436.97~0~J2.4~end~~4.5pt~#A54B4B^^0~736~-435^^0~M 739 -432 L 742 -435 L 739 -438#@$P~show~3~J2.3~720~-425~180~gge2665~0^^720~-425^^M 720 -425 h 19.685~#A54B4B^^1~749.84~-422.047~0~HV~start~~4.5pt~#A54B4B^^1~728.19~-426.97~0~J2.3~end~~4.5pt~#A54B4B^^0~736~-425^^0~M 739 -422 L 742 -425 L 739 -428#@$P~show~3~J2.2~720~-415~180~gge2686~0^^720~-415^^M 720 -415 h 19.685~#A54B4B^^1~749.84~-412.047~0~HV2~start~~4.5pt~#A54B4B^^1~728.19~-416.97~0~J2.2~end~~4.5pt~#A54B4B^^0~736~-415^^0~M 739 -412 L 742 -415 L 739 -418#@$P~show~3~J2.1~720~-405~180~gge2707~0^^720~-405^^M 720 -405 h 19.685~#A54B4B^^1~749.84~-402.047~0~HV1~start~~4.5pt~#A54B4B^^1~728.19~-406.97~0~J2.1~end~~4.5pt~#A54B4B^^0~736~-405^^0~M 739 -402 L 742 -405 L 739 -408#@$PL~740.31 -395 740.31 -465~#A54B4B~1~0~none~gge2728~0#@$PL~740.31 -465 820.31 -465~#A54B4B~1~0~none~gge2731~0#@$PL~820.31 -465 820.31 -395~#A54B4B~1~0~none~gge2734~0#@$PL~820.31 -395 740.31 -395~#A54B4B~1~0~none~gge2737~0#@$P~show~3~J1.6~840~-455~0~gge2740~0^^840~-455^^M 840 -455 h -19.685~#A54B4B^^1~810.79~-452.047~0~LV4~end~~4.5pt~#A54B4B^^1~832.44~-456.97~0~J1.6~start~~4.5pt~#A54B4B^^0~824~-455^^0~M 821 -458 L 818 -455 L 821 -452",
          "W~330 -285 330 -245 465 -245~#FF0000~1~0~none~gge2761~0",
          "F~part_netLabel_gnD~295~-345~270~gge2767~~0^^295~-345^^GND~#000000~252~-341.07~0~start~1~Times New Roman~9pt~flag_gge7^^PL~285 -345 295 -345~#000000~1~0~transparent~gge2779~0^^PL~285 -354 285 -336~#000000~1~0~transparent~gge2782~0^^PL~283 -351 283 -339~#000000~1~0~transparent~gge2785~0^^PL~281 -348 281 -342~#000000~1~0~transparent~gge2788~0^^PL~279 -346 279 -344~#000000~1~0~transparent~gge2791~0",
          "F~part_netLabel_gnD~665~-360~270~gge2797~~0^^665~-360^^GND~#000000~622.5~-355.93~0~start~1~Times New Roman~9pt~flag_gge10^^PL~655 -360 665 -360~#000000~1~0~transparent~gge2809~0^^PL~655 -369 655 -351~#000000~1~0~transparent~gge2812~0^^PL~653 -366 653 -354~#000000~1~0~transparent~gge2815~0^^PL~651 -363 651 -357~#000000~1~0~transparent~gge2818~0^^PL~649 -361 649 -359~#000000~1~0~transparent~gge2821~0",
          "F~part_netLabel_+5V~400~-245~180~gge2824~~0^^400~-245^^+12V~#FF0000~389.29~-223.79~0~start~1~Times New Roman~9pt~flag_gge13^^PL~400 -235 400 -245~#FF0000~1~0~transparent~gge2836~0^^PL~405 -235 395 -235~#FF0000~1~0~transparent~gge2839~0",
          "W~625 -405 720 -405~#00FF00~1~0~none~gge2842~0",
          "W~625 -415 720 -415~#FFFF00~1~0~none~gge2845~0",
          "W~625 -395 680 -395 680 -425 720 -425~#FF0000~1~0~none~gge2848~0",
          "W~625 -245 680 -245 680 -395~#FF0000~1~0~none~gge2851~0",
          "F~part_netLabel_+5V~755~-245~180~gge2854~~0^^755~-245^^+5V~#FF0000~744.28~-224~0~start~1~Times New Roman~9pt~flag_gge16^^PL~755 -235 755 -245~#FF0000~1~0~transparent~gge2866~0^^PL~760 -235 750 -235~#FF0000~1~0~transparent~gge2869~0",
          "W~330 -305 305 -305 305 -405 495 -405~#FFFF00~1~0~none~gge2872~0",
          "W~495 -395 315 -395 315 -325 330 -325~#00FF00~1~0~none~gge2875~0",
          "W~840 -405 925 -405 925 -575 725 -575~#00FF00~1~0~none~gge2911~0",
          "W~840 -415 915 -415 915 -595 725 -595~#FFFF00~1~0~none~gge2914~0",
          "W~725 -535 940 -535 940 -245 680 -245~#FF0000~1~0~none~gge2917~0",
          "W~840 -425 905 -425 905 -485 555 -485 555 -535 575 -535~#FF0000~1~0~none~gge2920~0",
          "F~part_netLabel_+5V~855~-485~0~gge2923~~0^^855~-485^^+3.3V~#FF0000~844.28~-498~0~start~1~Times New Roman~9pt~flag_gge19^^PL~855 -495 855 -485~#FF0000~1~0~transparent~gge2935~0^^PL~850 -495 860 -495~#FF0000~1~0~transparent~gge2938~0",
          "W~575 -685 545 -685 545 -475~#000000~1~0~none~gge2941~0",
          "LIB~340~-690~package`CONN-TH_P5.00_KF301-5.0-2P`Contributor`LCSC`Supplier`LCSC`Supplier Part`C474881`Manufacturer`KEFA(科发)`Manufacturer Part`KF301-5.0-2P`JLCPCB Part Class`Extended Part`spicePre`U`spiceSymbolName`KF301-5.0-2P`~~0~ggecb3ea82304750410~c444d117946441c3ab8b7492a6a9cd72~45ddbab4559a43c6bc95d2ca22fb25a0~0~~yes~yes~123d364278a842e38f921357b5b39451~1698742815~925b7d4d3ad04b178b0b30c8fb0c2a89#@$T~N~315.94~-721.67~0~#000080~Arial~~~~~comment~KF301-5.0-2P~1~start~gge2950~0~#@$T~P~331.44~-711.84~0~#000080~Arial~~~~~comment~U13~1~start~gge2956~0~#@$R~330~-705~2~2~20~30~#880000~1~0~none~gge2962~0~#@$E~335~-700~1.5~1.5~#880000~1~0~#880000~gge2965~0#@$P~show~0~1~320~-695~180~gge2968~0^^320~-695^^M 320 -695 h 10~#880000^^1~333.7~-691~0~1~start~~~#0000FF^^1~329.5~-696~0~1~end~~~#0000FF^^0~327~-695^^0~M 330 -692 L 333 -695 L 330 -698#@$P~show~0~2~320~-685~180~gge2989~0^^320~-685^^M 320 -685 h 10~#880000^^1~333.7~-681~0~2~start~~~#0000FF^^1~329.5~-686~0~2~end~~~#0000FF^^0~327~-685^^0~M 330 -682 L 333 -685 L 330 -688",
          "LIB~340~-640~package`CONN-TH_P5.00_KF301-5.0-2P`Contributor`LCSC`Supplier`LCSC`Supplier Part`C474881`Manufacturer`KEFA(科发)`Manufacturer Part`KF301-5.0-2P`JLCPCB Part Class`Extended Part`spicePre`U`spiceSymbolName`KF301-5.0-2P`~~0~gge9833f011e8270712~c444d117946441c3ab8b7492a6a9cd72~45ddbab4559a43c6bc95d2ca22fb25a0~0~~yes~yes~123d364278a842e38f921357b5b39451~1698742815~925b7d4d3ad04b178b0b30c8fb0c2a89#@$T~N~380.94~-636.67~0~#000080~Arial~~~~~comment~KF301-5.0-2P~0~start~gge3016~0~#@$T~P~331.44~-661.84~0~#000080~Arial~~~~~comment~U12~1~start~gge3022~0~#@$R~330~-655~2~2~20~30~#880000~1~0~none~gge3028~0~#@$E~335~-650~1.5~1.5~#880000~1~0~#880000~gge3031~0#@$P~show~0~1~320~-645~180~gge3034~0^^320~-645^^M 320 -645 h 10~#880000^^1~333.7~-641~0~1~start~~~#0000FF^^1~329.5~-646~0~1~end~~~#0000FF^^0~327~-645^^0~M 330 -642 L 333 -645 L 330 -648#@$P~show~0~2~320~-635~180~gge3055~0^^320~-635^^M 320 -635 h 10~#880000^^1~333.7~-631~0~2~start~~~#0000FF^^1~329.5~-636~0~2~end~~~#0000FF^^0~327~-635^^0~M 330 -632 L 333 -635 L 330 -638",
          "LIB~340~-590~package`CONN-TH_P5.00_KF301-5.0-2P`Contributor`LCSC`Supplier`LCSC`Supplier Part`C474881`Manufacturer`KEFA(科发)`Manufacturer Part`KF301-5.0-2P`JLCPCB Part Class`Extended Part`spicePre`U`spiceSymbolName`KF301-5.0-2P`~~0~gge5f834e0651928cea~c444d117946441c3ab8b7492a6a9cd72~45ddbab4559a43c6bc95d2ca22fb25a0~0~~yes~yes~123d364278a842e38f921357b5b39451~1698742815~925b7d4d3ad04b178b0b30c8fb0c2a89#@$T~N~380.94~-586.67~0~#000080~Arial~~~~~comment~KF301-5.0-2P~0~start~gge3082~0~#@$T~P~331.79~-611.84~0~#000080~Arial~~~~~comment~U11~1~start~gge3088~0~#@$R~330~-605~2~2~20~30~#880000~1~0~none~gge3094~0~#@$E~335~-600~1.5~1.5~#880000~1~0~#880000~gge3097~0#@$P~show~0~1~320~-595~180~gge3100~0^^320~-595^^M 320 -595 h 10~#880000^^1~333.7~-591~0~1~start~~~#0000FF^^1~329.5~-596~0~1~end~~~#0000FF^^0~327~-595^^0~M 330 -592 L 333 -595 L 330 -598#@$P~show~0~2~320~-585~180~gge3121~0^^320~-585^^M 320 -585 h 10~#880000^^1~333.7~-581~0~2~start~~~#0000FF^^1~329.5~-586~0~2~end~~~#0000FF^^0~327~-585^^0~M 330 -582 L 333 -585 L 330 -588",
          "LIB~340~-540~package`CONN-TH_P5.00_KF301-5.0-2P`Contributor`LCSC`Supplier`LCSC`Supplier Part`C474881`Manufacturer`KEFA(科发)`Manufacturer Part`KF301-5.0-2P`JLCPCB Part Class`Extended Part`spicePre`U`spiceSymbolName`KF301-5.0-2P`~~0~gge4f7b50b6f1d27bcc~c444d117946441c3ab8b7492a6a9cd72~45ddbab4559a43c6bc95d2ca22fb25a0~0~~yes~yes~123d364278a842e38f921357b5b39451~1698742815~925b7d4d3ad04b178b0b30c8fb0c2a89#@$T~N~380.94~-531.67~0~#000080~Arial~~~~~comment~KF301-5.0-2P~0~start~gge3148~0~#@$T~P~331.44~-561.84~0~#000080~Arial~~~~~comment~U10~1~start~gge3154~0~#@$R~330~-555~2~2~20~30~#880000~1~0~none~gge3160~0~#@$E~335~-550~1.5~1.5~#880000~1~0~#880000~gge3163~0#@$P~show~0~1~320~-545~180~gge3166~0^^320~-545^^M 320 -545 h 10~#880000^^1~333.7~-541~0~1~start~~~#0000FF^^1~329.5~-546~0~1~end~~~#0000FF^^0~327~-545^^0~M 330 -542 L 333 -545 L 330 -548#@$P~show~0~2~320~-535~180~gge3187~0^^320~-535^^M 320 -535 h 10~#880000^^1~333.7~-531~0~2~start~~~#0000FF^^1~329.5~-536~0~2~end~~~#0000FF^^0~327~-535^^0~M 330 -532 L 333 -535 L 330 -538",
          "LIB~340~-490~package`CONN-TH_P5.00_KF301-5.0-2P`Contributor`LCSC`Supplier`LCSC`Supplier Part`C474881`Manufacturer`KEFA(科发)`Manufacturer Part`KF301-5.0-2P`JLCPCB Part Class`Extended Part`spicePre`U`spiceSymbolName`KF301-5.0-2P`~~0~ggee19afa480a5b9422~c444d117946441c3ab8b7492a6a9cd72~45ddbab4559a43c6bc95d2ca22fb25a0~0~~yes~yes~123d364278a842e38f921357b5b39451~1698742815~925b7d4d3ad04b178b0b30c8fb0c2a89#@$T~N~380.94~-486.67~0~#000080~Arial~~~~~comment~KF301-5.0-2P~0~start~gge3214~0~#@$T~P~334.04~-511.84~0~#000080~Arial~~~~~comment~U9~1~start~gge3220~0~#@$R~330~-505~2~2~20~30~#880000~1~0~none~gge3226~0~#@$E~335~-500~1.5~1.5~#880000~1~0~#880000~gge3229~0#@$P~show~0~1~320~-495~180~gge3232~0^^320~-495^^M 320 -495 h 10~#880000^^1~333.7~-491~0~1~start~~~#0000FF^^1~329.5~-496~0~1~end~~~#0000FF^^0~327~-495^^0~M 330 -492 L 333 -495 L 330 -498#@$P~show~0~2~320~-485~180~gge3253~0^^320~-485^^M 320 -485 h 10~#880000^^1~333.7~-481~0~2~start~~~#0000FF^^1~329.5~-486~0~2~end~~~#0000FF^^0~327~-485^^0~M 330 -482 L 333 -485 L 330 -488",
          "LIB~340~-440~package`CONN-TH_P5.00_KF301-5.0-2P`Contributor`LCSC`Supplier`LCSC`Supplier Part`C474881`Manufacturer`KEFA(科发)`Manufacturer Part`KF301-5.0-2P`JLCPCB Part Class`Extended Part`spicePre`U`spiceSymbolName`KF301-5.0-2P`~~0~gge1b887ea2562b5148~c444d117946441c3ab8b7492a6a9cd72~45ddbab4559a43c6bc95d2ca22fb25a0~0~~yes~yes~123d364278a842e38f921357b5b39451~1698742815~925b7d4d3ad04b178b0b30c8fb0c2a89#@$T~N~380.94~-436.67~0~#000080~Arial~~~~~comment~KF301-5.0-2P~0~start~gge3280~0~#@$T~P~334.04~-461.84~0~#000080~Arial~~~~~comment~U8~1~start~gge3286~0~#@$R~330~-455~2~2~20~30~#880000~1~0~none~gge3292~0~#@$E~335~-450~1.5~1.5~#880000~1~0~#880000~gge3295~0#@$P~show~0~1~320~-445~180~gge3298~0^^320~-445^^M 320 -445 h 10~#880000^^1~333.7~-441~0~1~start~~~#0000FF^^1~329.5~-446~0~1~end~~~#0000FF^^0~327~-445^^0~M 330 -442 L 333 -445 L 330 -448#@$P~show~0~2~320~-435~180~gge3319~0^^320~-435^^M 320 -435 h 10~#880000^^1~333.7~-431~0~2~start~~~#0000FF^^1~329.5~-436~0~2~end~~~#0000FF^^0~327~-435^^0~M 330 -432 L 333 -435 L 330 -438",
          "LIB~350~-125~package`KF301-4P`Manufacturer Part`KF301`Contributor`Slape_tex`spicePre`U`spiceSymbolName`KF301-4P`~270~0~gge9eb1395fc415354b~67e62fa529da40d7881fddd94d961dc1~298961acd3704ab88b8350683c41d7ec~0~~yes~yes~~1581027284~#@$T~N~340.05~-170~0~#000080~Arial~~~~~comment~KF301-4P~1~start~gge3476~0~#@$T~P~342.05~-179~0~#000080~Arial~~~~~comment~U1~1~start~gge3482~0~#@$PL~340 -165 340 -85.06 370.1 -85.1 370 -165 340 -165 340 -165~#880000~1~0~none~gge3488~0#@$E~353.1~-154.83~6.4~6.54~#880000~1~0~none~gge3491~0#@$E~365.5~-155.0625~1.625~1.5625~#880000~1~0~none~gge3494~0#@$PL~363.3 -165 363.3 -84.7~#880000~1~0~none~gge3497~0#@$PL~343.75 -165 343.7 -85~#880000~1~0~none~gge3500~0#@$E~353.1~-134.95~6.4~6.54~#880000~1~0~none~gge3503~0#@$E~365.495~-135.1825~1.625~1.5625~#880000~1~0~none~gge3506~0#@$R~363.78~-87~~~2.22~1.56~#880000~1~0~none~gge3509~0~#@$R~363.67~-167~~~2.33~1.6~#880000~1~0~none~gge3512~0~#@$P~show~0~1~330~-155~180~gge3515~0^^330~-155^^M 330 -155 h 10~#800000^^0~343~-152~0~1~start~~~#800000^^0~339~-156~0~1~end~~~#800000^^0~337~-155^^0~M 340 -152 L 343 -155 L 340 -158#@$P~show~0~2~330~-135~180~gge3536~0^^330~-135^^M 330 -135 h 10~#800000^^0~343~-132~0~2~start~~~#800000^^0~339~-136~0~2~end~~~#800000^^0~337~-135^^0~M 340 -132 L 343 -135 L 340 -138#@$E~353~-115~6.4~6.54~#880000~1~0~none~gge3557~0#@$E~365.31~-115.08~1.625~1.5625~#880000~1~0~none~gge3560~0#@$P~show~0~3~330~-115~180~gge3563~0^^330~-115^^M 330 -115 h 10~#800000^^0~343~-112~0~3~start~~~#800000^^0~339~-116~0~3~end~~~#800000^^0~337~-115^^0~M 340 -112 L 343 -115 L 340 -118#@$P~show~0~4~330~-95~180~gge3584~0^^330~-95^^M 330 -95 h 10~#800000^^0~343~-92~0~4~start~~~#800000^^0~339~-96~0~4~end~~~#800000^^0~337~-95^^0~M 340 -92 L 343 -95 L 340 -98#@$E~353.2~-94.96~6.4~6.54~#880000~1~0~none~gge3605~0#@$E~365.16~-95.07~1.625~1.5625~#880000~1~0~none~gge3608~0",
          "T~L~370~-305~0~#0000FF~~9pt~~~~comment~B-~1~start~gge3611~0~pinpart",
          "T~L~370~-320~0~#0000FF~~9pt~~~~comment~A+~1~start~gge3617~0~pinpart",
          "T~L~370~-115~0~#0000FF~~9pt~~~~comment~B-~1~start~gge3632~0~pinpart",
          "T~L~370~-135~0~#0000FF~~9pt~~~~comment~A+~1~start~gge3641~0~pinpart",
          "LIB~580~-100~package`UART-TTL-RS485. V2`Manufacturer``Manufacturer Part``Supplier Part``Supplier``link``Contributor`Compesalogger`spicePre`U`spiceSymbolName`UART-TTL-RS485_HW-519`~180~0~ggee0ce7ec00835ac6c~a58176efddf245e39b56214be2bba8af~14d4e9a8b2d848bcaaae66a37d5ab510~0~~yes~yes~f0253c41cbd14a72bb146076879619c8~1692093619~4392aeb98460419fae1830a3f532e153#@$T~N~477.33~-156.75~0~#000080~Arial~~~~~comment~UART-TTL-RS485_HW-519~1~start~gge3656~0~#@$T~P~459.03~-156.75~0~#000080~Arial~~~~~comment~U2~1~start~gge3662~0~#@$P~show~0~1~590~-110~0~gge3668~0^^590~-110^^M 590 -110 h -20~#880000^^1~568~-107~0~VCC~end~~6.5pt~#0000FF^^1~575~-111~0~1~start~~6.5pt~#0000FF^^0~573~-110^^0~M 570 -113 L 567 -110 L 570 -107#@$P~show~0~2~590~-120~0~gge3689~0^^590~-120^^M 590 -120 h -20~#880000^^1~568~-117~0~TXD~end~~6.5pt~#0000FF^^1~575~-121~0~2~start~~6.5pt~#0000FF^^0~573~-120^^0~M 570 -123 L 567 -120 L 570 -117#@$P~show~0~3~590~-130~0~gge3710~0^^590~-130^^M 590 -130 h -20~#880000^^1~568~-127~0~RXD~end~~6.5pt~#0000FF^^1~575~-131~0~3~start~~6.5pt~#0000FF^^0~573~-130^^0~M 570 -133 L 567 -130 L 570 -127#@$P~show~0~4~590~-140~0~gge3731~0^^590~-140^^M 590 -140 h -20~#880000^^1~568~-137~0~GND~end~~6.5pt~#0000FF^^1~575~-141~0~4~start~~6.5pt~#0000FF^^0~573~-140^^0~M 570 -143 L 567 -140 L 570 -137#@$P~show~0~5~460~-140~180~gge3752~0^^460~-140^^M 460 -140 h 20~#880000^^1~482~-137~0~GND~start~~6.5pt~#0000FF^^1~475~-141~0~5~end~~6.5pt~#0000FF^^0~477~-140^^0~M 480 -137 L 483 -140 L 480 -143#@$P~show~0~6~460~-120~180~gge3773~0^^460~-120^^M 460 -120 h 20~#880000^^1~482~-117~0~B-~start~~6.5pt~#0000FF^^1~475~-121~0~6~end~~6.5pt~#0000FF^^0~477~-120^^0~M 480 -117 L 483 -120 L 480 -123#@$P~show~0~7~460~-110~180~gge3794~0^^460~-110^^M 460 -110 h 20~#880000^^1~482~-107~0~A+~start~~6.5pt~#0000FF^^1~475~-111~0~7~end~~6.5pt~#0000FF^^0~477~-110^^0~M 480 -107 L 483 -110 L 480 -113#@$R~480~-150~5~5~90~50~#990000~1~0~none~gge3815~0~#@$T~L~507.5~-104~0~#990000~~5.5pt~~~~comment~HW-519~1~start~gge3818~0~pinpart#@$T~L~497~-114~0~#990000~~5.5pt~~~~comment~AutoDetect~1~start~gge3824~0~pinpart",
          "W~330 -115 260 -115 260 -200 405 -200 405 -120 460 -120~#FFFF00~1~0~none~gge3833~0",
          "W~330 -135 270 -135 270 -190 395 -190 395 -110 460 -110~#00FF00~1~0~none~gge3836~0",
          "F~part_netLabel_gnD~460~-140~270~gge3842~~0^^460~-140^^GND~#000000~412~-136.07~0~start~1~Times New Roman~9pt~flag_gge22^^PL~450 -140 460 -140~#000000~1~0~transparent~gge3854~0^^PL~450 -149 450 -131~#000000~1~0~transparent~gge3857~0^^PL~448 -146 448 -134~#000000~1~0~transparent~gge3860~0^^PL~446 -143 446 -137~#000000~1~0~transparent~gge3863~0^^PL~444 -141 444 -139~#000000~1~0~transparent~gge3866~0",
          "F~part_netLabel_+5V~590~-110~270~gge3872~~0^^590~-110^^+5V~#FF0000~600.5~-106.07~0~start~1~Times New Roman~9pt~flag_gge25^^PL~600 -110 590 -110~#FF0000~1~0~transparent~gge3884~0^^PL~600 -115 600 -105~#FF0000~1~0~transparent~gge3887~0",
          "F~part_netLabel_gnD~590~-140~90~gge3896~~0^^590~-140^^GND~#000000~606.5~-136.07~0~start~1~Times New Roman~9pt~flag_gge28^^PL~600 -140 590 -140~#000000~1~0~transparent~gge3908~0^^PL~600 -131 600 -149~#000000~1~0~transparent~gge3911~0^^PL~602 -134 602 -146~#000000~1~0~transparent~gge3914~0^^PL~604 -137 604 -143~#000000~1~0~transparent~gge3917~0^^PL~606 -139 606 -141~#000000~1~0~transparent~gge3920~0",
          "W~590 -130 635 -130~#008800~1~0~none~gge3926~0",
          "F~part_netLabel_netPort~635~-130~180~gge3929~~0^^635~-130^^HV3~#0000FF~657~-126.28~0~start~1~Times New Roman~8pt~flag_gge31^^PL~635 -130 640 -135 655 -135 655 -125 640 -125 635 -130~#0000FF~1~0~transparent~gge3941~0",
          "W~590 -120 635 -120~#008800~1~0~none~gge3962~0",
          "F~part_netLabel_netPort~635~-120~180~gge3968~~0^^635~-120^^HV4~#0000FF~657~-116.28~0~start~1~Times New Roman~8pt~flag_gge34^^PL~635 -120 640 -125 655 -125 655 -115 640 -115 635 -120~#0000FF~1~0~transparent~gge3980~0",
          "F~part_netLabel_netPort~720~-445~0~gge3986~~0^^720~-445^^HV3~#0000FF~677.26~-441.57~0~start~1~Times New Roman~8pt~flag_gge37^^PL~720 -445 715 -440 700 -440 700 -450 715 -450 720 -445~#0000FF~1~0~transparent~gge3998~0",
          "F~part_netLabel_netPort~720~-455~0~gge4004~~0^^720~-455^^HV4~#0000FF~677.26~-451.57~0~start~1~Times New Roman~8pt~flag_gge40^^PL~720 -455 715 -450 700 -450 700 -460 715 -460 720 -455~#0000FF~1~0~transparent~gge4016~0",
          "F~part_netLabel_netPort~725~-675~180~gge4022~~0^^725~-675^^LV4~#0000FF~747~-671.28~0~start~1~Times New Roman~8pt~flag_gge43^^PL~725 -675 730 -680 745 -680 745 -670 730 -670 725 -675~#0000FF~1~0~transparent~gge4034~0",
          "F~part_netLabel_netPort~725~-655~180~gge4037~~0^^725~-655^^LV3~#0000FF~747~-651.28~0~start~1~Times New Roman~8pt~flag_gge46^^PL~725 -655 730 -660 745 -660 745 -650 730 -650 725 -655~#0000FF~1~0~transparent~gge4049~0",
          "F~part_netLabel_netPort~840~-445~180~gge4073~~0^^840~-445^^LV3~#0000FF~862~-441.28~0~start~1~Times New Roman~8pt~flag_gge49^^PL~840 -445 845 -450 860 -450 860 -440 845 -440 840 -445~#0000FF~1~0~transparent~gge4085~0",
          "F~part_netLabel_netPort~840~-455~180~gge4094~~0^^840~-455^^LV4~#0000FF~862~-451.28~0~start~1~Times New Roman~8pt~flag_gge52^^PL~840 -455 845 -460 860 -460 860 -450 845 -450 840 -455~#0000FF~1~0~transparent~gge4106~0",
          "F~part_netLabel_gnD~495~-425~270~gge4196~~0^^495~-425^^GND~#000000~452~-421.07~0~start~1~Times New Roman~9pt~flag_gge55^^PL~485 -425 495 -425~#000000~1~0~transparent~gge4208~0^^PL~485 -434 485 -416~#000000~1~0~transparent~gge4211~0^^PL~483 -431 483 -419~#000000~1~0~transparent~gge4214~0^^PL~481 -428 481 -422~#000000~1~0~transparent~gge4217~0^^PL~479 -426 479 -424~#000000~1~0~transparent~gge4220~0",
          "W~625 -295 665 -295 665 -425 625 -425~#000000~1~0~none~gge4286~0",
          "W~545 -475 665 -475 665 -425~#000000~1~0~none~gge4297~0",
          "W~840 -435 885 -435 885 -475 665 -475~#000000~1~0~none~gge4305~0",
          "W~720 -435 665 -435~#000000~1~0~none~gge4309~0",
          "F~part_netLabel_+5V~330~-95~90~gge4404~~0^^330~-95^^+12V~#FF0000~292.07~-91.07~0~start~1~Times New Roman~9pt~flag_gge58^^PL~320 -95 330 -95~#FF0000~1~0~transparent~gge4416~0^^PL~320 -90 320 -100~#FF0000~1~0~transparent~gge4419~0",
          "F~part_netLabel_gnD~325~-155~270~gge4425~~0^^325~-155^^GND~#000000~277~-151.07~0~start~1~Times New Roman~9pt~flag_gge61^^PL~315 -155 325 -155~#000000~1~0~transparent~gge4437~0^^PL~315 -164 315 -146~#000000~1~0~transparent~gge4440~0^^PL~313 -161 313 -149~#000000~1~0~transparent~gge4443~0^^PL~311 -158 311 -152~#000000~1~0~transparent~gge4446~0^^PL~309 -156 309 -154~#000000~1~0~transparent~gge4449~0",
          "W~325 -155 330 -155~#000000~1~0~none~gge4616~0",
          "W~330 -345 325 -345 325 -380 415 -380 415 -305 415 -295 465 -295~#000000~1~0~none~gge4619~0",
          "W~295 -345 325 -345~#000000~1~0~none~gge4632~0",
          "J~555~-610~2.5~#CC0000~gge250~0",
          "J~555~-535~2.5~#CC0000~gge259~0",
          "J~680~-395~2.5~#CC0000~gge286~0",
          "J~755~-245~2.5~#FF0000~gge322~0",
          "J~855~-485~2.5~#FF0000~gge349~0",
          "J~665~-360~2.5~#CC0000~gge4294~0",
          "J~665~-425~2.5~#CC0000~gge4299~0",
          "J~545~-685~2.5~#000000~gge241~0",
          "J~545~-600~2.5~#000000~gge232~0",
          "J~665~-475~2.5~#CC0000~gge4306~0",
          "J~665~-435~2.5~#CC0000~gge4310~0",
          "J~680~-245~2.5~#FF0000~gge313~0",
          "J~400~-245~2.5~#CC0000~gge277~0",
          "J~325~-345~2.5~#CC0000~gge4633~0"
        ],
        "BBox": {
          "x": 0,
          "y": -806.8,
          "width": 1149.8,
          "height": 807.4
        },
        "colors": {}
      }
    }
  ]
}

djtef · Janvier 5, 2025, 5:09

Exactement pareil chez moi, tout est démonté vu que j’y trafique sans arrêt

djtef · Janvier 5, 2025, 5:20

Très bonne initiative, j’avais ça en tête également.
Perso je pensais mettre un système (avec un relais ou autre) pour pouvoir rebasculer le modbus sur la commande centrale en cas de besoin.
Si tu veux fusionner tous nos cas d’usage, en plus de mon côté :

je lis les températures des sondes haut et bas ECS directement avec l’esp32. Je les intercepte et les renvoie à la carte mère. Mes mesures collent à 0.2° à celles affichées par la télécommande.
je reçois la commande de la résistance d’appoint

Ainsi c’est moi qui commande la résistance quand :

la carte mère la commande pour le cycle anti légionellose à 60°
mon routeur solaire renvoie le surplus

Et je peux couper le routeur quand la sonde haute ou basse arrive à 80° (avec en backup le retour de la température via le modbus)
Au niveau de la carte ça rajoute pas grand chose à part un double connecteur pour les températures qui vont sur deux entrées analogiques et un autre connecteur simple vers une entrée discrète. Mais il faut qu’il reste des pinouilles dispo sur l’esp32 sinon faut ajouter un ads1115 en i2c.

guix77 · Janvier 5, 2025, 5:34

Ah OK, ton UART utilise les bonnes pin sur ton PCB mais dans le yaml tu as GPIO4 et 5.

Le PCB me semble OK du coup, si tu peux encore augmenter la largeur d’un cran c’est mieux, mais attention j’ai pas compris si EasyEDA gère correctement l’eloignement des pistes

Il te faudrait 0.386mm selon Trace Width Calculator | AdvancedPCB

guix77 · Janvier 5, 2025, 5:40

En fait je me suis trompé, avec une piste au-dessus et une en-dessous on est en external layer air, donc même le 0.254mm de base est amplement suffisant

djtef · Janvier 5, 2025, 5:42

J’avais lu quelques recommendations de conception pcb quand j’avais commencé, les principales sont :

Ne pas hésiter à mettre les pistes d’alimentation (3 et 5V) plus larges et de préférence d’un seul côté, et le plus éloigné possible des autres pistes analogiques et binaires.
Ajouter un plan de masse sur chaque face (c’est facile avec Easyeda)
Mettre un condensateur sur l’alimentation de l’esp, le plus proche possible de sa pinouille

Hugz · Janvier 5, 2025, 11:08

Eurêka !!
J’ai bien galéré, mais j’ai réussi à faire fonctionner les deux Modbus en simultané sur le même ESP32 ! Le YAML n’était pas tout à fait correct, et j’ai cramé un convertisseur TTL-RS485 suite à une erreur de branchement .
J’ai utilisé deux de mes PCB pour créer une sorte de banc de test.

Pour résumer :
J’alimente les deux PCB avec le 12V de leur Modbus respectif.
J’alimente le level shifter en 3.3V via l’ESP du petit PCB.
Je dérive les broches GPIO16 et GPIO17 de l’emplacement vide de l’ESP32 du gros PCB vers les broches GPIO3 et GPIO1 (TXD/RXD) de l’ESP32 sur le petit PCB.

Pour le code YAML, il faut ajouter la balise « modbus » en plus. C’est elle qui porte l’information de l’UART et non plus le « modbus_controller »
comme quoi, lire la doc, ça sert

extrait:

uart:
  - id: uart_motherboard
    baud_rate: 19200
    tx_pin: GPIO16
    rx_pin: GPIO17
    parity: EVEN
  - id: uart_central_command
    baud_rate: 19200
    tx_pin: GPIO3
    rx_pin: GPIO1
    parity: EVEN

modbus:
  - uart_id: uart_motherboard
    id: modbus_motherboard
  - uart_id: uart_central_command
    id: modbus_central_command

modbus_controller:
  - id: motherboard
    modbus_id: modbus_motherboard
    address: 0x1
  - id: central_command
    modbus_id: modbus_central_command
    address: 0x1

sensor:
  - platform: modbus_controller
    modbus_controller_id: motherboard
    name: "Temperature principale"
    device_class: temperature
    state_class: measurement
    register_type: holding
    address: 0x0078
    value_type: S_WORD
    unit_of_measurement: "°C"
    accuracy_decimals: 1
    filters:
      - multiply: 0.01
  - platform: modbus_controller
    modbus_controller_id: central_command
    name: "Temperature K1a séjour"
    device_class: temperature
    state_class: measurement
    register_type: holding
    address: 190
    value_type: S_WORD
    unit_of_measurement: "°C"
    accuracy_decimals: 1
    filters:
      - multiply: 0.01
  - platform: modbus_controller
    modbus_controller_id: central_command
    name: "Temperature K4 palier"
    device_class: temperature
    state_class: measurement
    register_type: holding
    address: 194
    value_type: S_WORD
    unit_of_measurement: "°C"
    accuracy_decimals: 1
    filters:
      - multiply: 0.01

Hugz · Janvier 6, 2025, 3:50

@djtef

Question sans doute un peu naïve, mais est-ce qu’il ne suffirait pas de mettre des Wago sur les quatre fils du Modbus de la commande centrale pour faire fonctionner les deux en parallèle ?
Sur le 12v et GND c’est sur que oui mais sur le A+ et B- ?

djtef · Janvier 6, 2025, 4:55

Non c’est pas possible, il peut n’y avoir qu’un maître en modbus, soit l’esp soit la télécommande, sinon il y a conflit.
